Specifications
RF Power Output Power Max. 4 W
Frequency Range 406 – 470 MHz
VHF/UHF UHF
Maximum Channels Per Radio 512 (Up to 1000 Channels with option)
Number of zones 128
Analog Yes
Digital Yes
Channel Spacing – Analog 12.5 / 15 / 25* / 30* kHz
Channel Spacing – Digital 6.5 / 12.5 kHz
Power Supply 7.5 V DC ±20 %
IP Rating IP54/55/67 *
Features
Keypad Standard
Display Yes
Bluetooth Yes
GPS Yes
Audio Recording Yes
Emergency Yes
Key Lock Yes
Available License Keys
Model Description
KWD-3000CH Activate 1000 CH Expansion in NX-3000 Series
KWD-3001FP Activate Front Panel Programming in NX-3000 Series
KWD-3002BT Activate Bluetooth Serial Port Profile in NX-3000 Series for Bluetooth Data
KWD-3501TR Activate NXDN Type-C Trunking in NX-3000 Series
KWD-3502EE Activate DMR 40-bit ARC4 Enhanced Encryption for NX-3000 Series
KWD-3503AE Activate 256-bit AES and 56-bit DES encryption.
KWD-3504RC Activate remote control feature commands: Stun, Kill & Revive in NX-3000 Series
KWD-3505DE Activate 56-bit DES encryption.
KWD-3500CV NXDN Conventional and DMR Tier 2 manufacturer pre-installed License
KWD-3302TR Activate DMR Tier 3 Trunking License for NX-3000 Series. (Requires Tier 2 License)
*All interfaces must be fully sealed with appropriate covers or by designated genuine accessories.
*25 and 30 kHz are not included in the models sold in the USA or US territories.
